Torque range...... 4 - 220 lb.-in.
Part number........B220 - (voltage) - 1, for a shaft out 1 side (as shown)
Part number........B220 - (voltage) - 2, for a shaft out 2 sides
Coil voltages.......12, 24, 90 volts D.C.
Specify a 24 volt coil when used with a Placid Ind. power supply
